What Model do I have? Start here
February 17, 2008
4:28 pm
460smdave
Member
Forum Posts: 135
Member Since:
January 22, 2008
Offline

If you are searching for your model, please be sure to visit all the posts; yours has probably already been identified. Think of it as a puzzle; the answer is already in this thread….somewhere!  Happy hunting!  Best Regards, Ron (rwsem)



Small frame models.

  • 11 (357 Mag) Service Pork Chop PHOTO
  • 12 (357 Mag) Target Pork Chop PHOTO
  • 14 (357 Mag) Service Pork Chop PHOTO
  • 15 (357 Mag) Target Pork Chop  PHOTO 1  PHOTO 2
  • 14-2 (357 Mag) Service  PHOTO
  • 15-2 (357 Mag) Target PHOTO
  • 722 (.22 Long Rifle) Target
  • 22M (.22 Win. Mag) Target
  • 722M (.22 Win. Mag) Target
  • 8-2 (.38 Special) Service  PHOTO
  • 708 (.38 Special) Service
  • 9-2 (.38 Special) Target
  • 709 (.38 Special) Target
  • 714 (.357 Mag) Service  PHOTO
  • 715 (.357 Mag) Target  PHOTO

Models starting with a 7 are stainless guns.
Service models had fixed rear sights
Target models have adjustable rear sights

There are other models please help fill in the blanks.

The most common small frame guns are the model 15 and 15-2, the thought is the -2 guns have minor differences when Monson started manufacturing the guns and labeled it the -2. One of the changes noted is shape of the hammer.

When Bob Serva bought the Dan Wesson company and moved it to Norwich NY, he retooled the shop with all new CNC machines and the first guns he produced were marked “First issue” they went back to labeling the model 15 and 715 dropping the -2.

Dave



Edit by CF; straightened out some model references & added a few photos. 2/2012

February 18, 2008
7:00 am
Jody
Salem, Virginia
Admin
Forum Posts: 6023
Member Since:
January 22, 2008
Offline

In looking at the Blue Book of Gun Values there are a few more:

Additional Small Frame Revolvers (not sure if the last 3 are small frame or not I was guessing on those.)

  • 32 – 32 H&R Mag
  • 732 – Stainless 32 H&R Mag
  • 38P – 38+P 5 Shot
  • 322 – 32-20 WCF
  • 7322 – Stainless 32-20 WCF
  • 375 – 375 Supermag
  • 40 – 357 Supermag
  • 740V – 357 Supermag

Now for some large frame:

  • 41 – 41 Mag
  • 414 Supermag
  • 44 – 44 Mag
  • 45 – 45 Colt
  • 45 Pin Gun (Blued and Stainless) – 45 ACP
  • 445 Supermag – 445 Supermag
  • 741 – 41 Mag
  • 744 – 44 Mag
  • 745 – 45 Colt
  • 7414 – 414 Supermag
  • 7445 – 445 Supermag

Someone please correct me if I’m wrong.  I’m also going to make this a sticky for easy reference.

February 18, 2008
7:15 pm
460smdave
Member
Forum Posts: 135
Member Since:
January 22, 2008
Offline

Great first sticky, you know how many times on the net this has been asked.

Dave

February 22, 2008
1:35 pm
Jody
Salem, Virginia
Admin
Forum Posts: 6023
Member Since:
January 22, 2008
Offline

This information was compiling from the post on the Graybeard forum site. I would like to take everyone on that site that contributed to this list as well as our members here.

Models starting with a 7 are stainless guns.
Service models had fixed rear sights
Target models have adjustable rear sights

Small frame models

  • 8-2 (.38 Special) Service
  • 9-2 (.38 Special) Target
  • 11 (357 Mag) Service Pork Chop
  • 12 (357 Mag) Target Pork Chop
  • 14 (357 Mag) Service Pork Chop
  • 14-2 (.357 Mag) Service
  • 15 (357 Mag) Target Pork Chop
  • 14 (357 Mag) Service
  • 15 (357 Mag) Target
  • 15-2 (.357 Mag) Target
  • 22 (22LR) Target
  • 22M (.22 Win. Mag) Target
  • 32 (32 H&R Mag)
  • 3220 (32-20 Winchester)
  • 708 (.38 Special) Service
  • 709 (.38 Special) Target
  • 714 (.357 Mag) Service
  • 715 (.357 Mag) Target
  • 722 (.22 Long Rifle) Target
  • 722M (.22 Win. Mag) Target
  • 732 (32 H&R Mag) stainless
  • 73220 (32-20 Winchester) stainless
  • 738P (38Sp +P)

Large frame

  • 41 (41 Magnum)
  • 44 (44 Magnum)
  • 45 (45 Long Colt)
  • 741 (41 Magnum) stainless
  • 744 (44 Magnum) stainless
  • 745 (45 Long Colt) stainless
  • 7360 (360 Dan Wesson) stainless Norwich Production only
  • 7460 (460 Rowland) stainless only Norwich production only also fires 45 acp, 45 Win Mag

Supermag Frame

  • 40 (357 Supermag- 357 Maximum)
  • 740 (357 Supermag – 357 Maximum) stainless
  • 375 (375 Supermag) Blued only Palmer production only.  (One member has reported having a Monson produced 375 SuperMag.  So they did make a limited number there.  There is no way to know the quantity but I image it's very low)  Added 2009-01-19.
  • 7414 (414 Supermag) stainless Palmer production 25 units Norwich production very limited (Don’t know if blued was ever produced???)
  • 445 (445 Supermag)
  • 7445 (445 Supermag) stainless

Single Action
During the Palmer manufacture period (Wesson Firearms Co., Inc) there were some single action only 22 caliber target guns manufactured . These models were only manufactured in blue or stainless with 10″ barrel assemblies, either vent or vent heavy. The single action only guns were designated with a 6 before the model number.

  • 622-V10 Blue, single action only 22 cal.
  • 622-VH10 Blue, single action only 22 cal.
  • 6722-V10 stainless, single action only 22 cal.
  • 6722VH10 stainless, single action only 22 cal.

Barrel Configurations
Because of the Dan Wesson interchangeable barrel system, when the guns were sold, the barrel size and type was usually part of the model designation. Obviously this would change if the user changed the barrel, but it is still an interesting part of the Dan Wesson equation.

1). Standard barrels having the solid rib without the heavy underlug were usually designated by the barrel length alone.

For example, as per the information posted above, a 357 magnum with adjustable sights is a model 15.

The same gun with the standard 8” barrel becomes a model 15-8

2). Barrels with the vent rib get a V prefix.

So our model 15 with an 8” vent rib barrel becomes a model 15-V8

3). The Heavy Underlug adds an H to the designation

So a Heavy vent rib 8” equipped gun becomes a model 15-VH8

4). The slots cut on some of the silhouette shrouds add an S to the end.

The most common was the 357 Supermag model 40 (or 740 stainless)

So a model 740 stainless with the 8” vent rib and slotted shroud is a model 740-V8S

Yes, there were even some heavy underlug slotted guns (don’t know why)

So then a 740 vent rib, heavy underlug, slotted shroud gun is a model 740-VH8S

In Summary:

V = Vent Rib

H = Heavy Underlug

2,4,6,8,10,12,15 = barrel length (12″ and 15″ were only available for 357 magnum model 15 and 715)

S = Slotted Shroud

Also note the barrel length is the actual length of the barrel, from the forcing cone to the muzzle crown. The shroud length is obviously less because of the area the barrel screws through the frame.

The Pistol Pac and Hunters Pac.

From very early on, the Dan Wesson Revolver has been offered as a Pistol Pac. Over the years, the contents of the Pistol Pac changed some, but most contained the following Items.

1.) Dan Wesson Revolver with an 8″ barrel assembly.

2.) Extra barrel assemblies in 2 1/2″, 4″ , and 6″ length.

3.) An extra grip

4.) 4 additional front sight blades (2 white or red, and 2 yellow)

5.) A belt buckle

6.) A Dan Wesson logo patch

7.) A wrench kit

8.) A Carrying Case

Pistol Pacs were designated by a “P” then the model number of the revolver frame, then the barrel shroud type (blank) for standard, “V” for vent, “VH” for Vent Heavy

Example:

P-715 = Stainless 357 mag. standard barrel shroud

P-41-V = Blued 41 magnum, Vent rib barrel shroud

P-745-VH = stainless 45 long colt, Vent Heavy Pistol Pac

The Hunter Pac was offered in all Magnum calibers from 22 magnum up through 445 Supermag (even the 375 was a catalog item)

The Hunter Pac contained the following items:

1). Dan Wesson Revolver with an 8″ Vent Heavy Shroud.

2). A Vent 8″ Shroud (only, no extra barrel), equipped with Burris scope mounts and a Burris scope in either 11/2x-4x variable or 2x fixed.

3). Barrel changing tool

4). Dan Wesson logo patch

5). Carrying case

Hunters Pacs were identified by an “HP” before the model number and then a “V” for variable scope or a “2” for fixed power scope.

Example:

HP22M-V = 22magnum blue with 1 1/2x – 4x scope

HP744-2 = 44 magnum stainless with 2x fixed scope.

Other Interesting Information

The most common small frame guns are the model 15 and 15-2, the thought is the -2 guns have minor differences when Monson started manufacturing the guns and labeled it the -2. One of the changes noted is shape of the hammer.

When Bob Serva bought the Dan Wesson company and moved it to Norwich NY, he retooled the shop with all new CNC machines and the first guns he produced were marked “First issue” they went back to labeling the model 15 and 715 dropping the -2.

There is also a SuperRam Silhouette version available in many calibers, Norwich production with an under cut partridge front sight covered with a slab-sided hood, the rear sight is a Bomar with 18 clicks per revolution. These guns are marked with a SRS-1 on the barrel hood.

The Model 11 service and the model 12 target both had the pork chop barrel shrouds and the exposed barrel nut on the end. The early Model 14 and 15 had the pork chop barrel shrouds, but the barrel nut was recessed. The pork chop shroud was redesigned to the current style when the model designation was changed to 14-2 and 15-2.

The stainless .38 Special Action Cup with the large slab barrel shroud was just designated as the “Action Cup”, no numerical model number.

February 22, 2008
7:14 pm
Jody
Salem, Virginia
Admin
Forum Posts: 6023
Member Since:
January 22, 2008
Offline

I feel this information is so useful and interesting that I have created two new pages to cover models.  The new pages are:

These two pages can be accessed from the Models page on the navigation bar.  If updated information is posted here I will update the new pages.

Thanks.

February 26, 2008
7:22 am
wdelack
Soon to be somewhere in Texas
Member
Forum Posts: 806
Member Since:
January 22, 2008
Offline

Excellent thread!

One correction:  The Action Cup is .38 Special only.  The one I have is based on the model 708 frame, but has no mill work done where the rear sight would typically be.  The AC is double action only as well.



Wayne

February 26, 2008
10:43 am
Jody
Salem, Virginia
Admin
Forum Posts: 6023
Member Since:
January 22, 2008
Offline

Hey Wayne,

Thanks for the correction.  I have updated the post above as well as the information under the Models section of the site.

 Jody

March 1, 2008
4:27 pm
Tom
Member
Forum Posts: 37
Member Since:
February 29, 2008
Offline

.

Thanks to Dave Laughing



i stepped on old Dan Wesson pages

containing model and price lists. Regarding them i feel that

catalogisizing the complete model/price history is even more

complicated as i thought before. How can we respect

the differerent eras of business and model-lines

although we do not have all informations jet ?

(Monson era, Norwich era, and others)

Please have a look at this infos: DW model + price-list



Regards Tom

November 19, 2008
6:22 pm
chirochic
Member
Forum Posts: 2
Member Since:
November 19, 2008
Offline

Ok, I'm new here and not sure I understand all of this.  I have a DW .357 My ex husband bought it from some guy who needed cash, over 20 years ago.  I have been told it is a collectable, but how do I tell?  It has a serial # but it doesn't have any of those letters listed.  I have shot it a few times but don't know much about the parts.  Like is it vented or not, or heavy under lug…..I don't know what these mean.  What do I need to do to see exactly what I have? Thanks in advance.

November 19, 2008
7:17 pm
Brian
Guest
10

Take a look at the revolver thread with pictures to start.  Is your gun blue or stainless?  How many inches long is the barrel”  Do the rear sights have a screw notch on the top and side for adjustment?

November 20, 2008
7:33 am
Robert Hoffman
Guest
11

It should also state where it was made; either Monson or Palmer.  The Monson models were the better finished guns and had fewer problems.  Does it have letters before the serial number?

January 17, 2009
7:04 pm
pops2
Guest
12

I saw by the model listing that you list the 375 super mag as only produced at palmer mass. Mine is blue 8″vhs but stamped monson mass. you might update your log. Also wanted to thank the forum for alot of information, keep it up.

January 19, 2009
7:57 am
Jody
Salem, Virginia
Admin
Forum Posts: 6023
Member Since:
January 22, 2008
Offline
13

Thanks Pops for the information.  Anyway you could provide us with a photo? There's so little information on the DW's so it's exciting when we find out new info like this.

Thanks again!

January 19, 2009
8:37 pm
pops2
Guest
14

I'm not good at this but will round up my DW's Three SM's, one b44, one palmer s22 and a DW pointman. I don't have a 41mag or 45lc YET.

January 22, 2009
7:18 am
IHMSA80x80
Member
Forum Posts: 2424
Member Since:
April 25, 2008
Offline
15

I also have a Monson-made .375 Supermag V8S. Here's a close-up.

The Savantist
January 22, 2009
8:59 am
Jody
Salem, Virginia
Admin
Forum Posts: 6023
Member Since:
January 22, 2008
Offline
16

Thanks for the picture IHMSA… Very nice looking SuperMag!

January 23, 2009
7:32 pm
pops2
Guest
17

Laugh

January 23, 2009
8:12 pm
pops2
Guest
18

Hello: not having any luck with pictures, I'll keep trying. I do have models and numbers but no production dates. No. 1  dan wesson, blue # 375Mb00111X, 8″VSshroud, monson, mass, Dan wesson arms, shroud marked .375 SM ctg. with orignal box.  No. 2 wesson firearms 722, # 22S00111X VH8″, palmer, mass. u.s.a., shroud marked cal.22 lr., with leupold clamp mt. and 8m 4x scope. Sweet shooter. the finish and stamping is great.No. 3 dan wesson arms, blue # 357MB00123X, 8″VS, monsom mass.u.s.a., shroud marked dan wesson arms .357 maximum ctg, left side super mag. No. 4 dan wesson arms, blue # 44B00309X, VH6″,monson mass.u.s.a., shroud marked,dan wesson arms .44 magnum ctg. buchler mt., with b&l 2X scope. No.5 wesson firearms, Pre AGS .445S00001X, palmer mass. u.s.a.,shroud marked .445 ctg, left side has .445 super mag. and dan wesson signature on end of shroud. This is compensated with knurled knob on the end of barrel and 4″ barrel, in plastic black box and papers with tool, also tephlon coated, another sweet shooter with some copper color showing on the shroud, this had a sale tag dated to 1992 in the box I bought this used,  No.6 is a dan wesson firearms, PMA-S PMA421X, stainless steel, .45acp, ausie mint in plastic black box with lock and papers, this is norwich, ny u.s.a. Sale date is spring of 2004. hope this helps will keep trying to get the pictures loaded. Again keep the faith and buy guns!

February 12, 2009
5:38 pm
ironhorse
Member
Forum Posts: 3
Member Since:
February 12, 2009
Offline
19

I have gone through all of the above posts, but am still unsure of exactly what I have.

It is a .44 magnum, stainless, 6″ barrel made in Palmer, Mass.

44S0038XX

It is not a vent rib barrel and I don't think that it has the interchangeable barrel.  I can't see any slots at the end of the barrel.

Any information would be appreciated.

Thanks

February 12, 2009
8:06 pm
Steve CT
Central CT
Admin
Forum Posts: 7825
Member Since:
March 2, 2008
Offline
20

http://www.danwessonforum.com/?page_id=3/revolvers/fixed-barrel-dws

This might help out, there were fixed barrel Dan Wesson revolvers (surprised me too).

Welcome to DWF. I hope you'll stop by New Members and tell us more about yourself.

Steve

Forum Timezone: America/New_York

Most Users Ever Online: 39

Currently Online:
15 Guest(s)

Currently Browsing this Page:
1 Guest(s)

Top Posters:

SHOOTIST357: 4570

Dave_Ks: 3750

Blacktop: 2990

zoommb: 2819

Supermagfan: 2639

IHMSA80x80: 2424

SCORPIO: 1651

Pinetor: 1569

jaggman: 1342

photohause: 1328

Newest Members:

Paul

Wasson Den

edfgrf1951

Tinkerer88

Ronnie Bolton

Ranger Bob

Forum Stats:

Groups: 11

Forums: 42

Topics: 10592

Posts: 95217

Member Stats:

Guest Posters: 87

Members: 3955

Moderators: 3

Admins: 2

Site Supporters: ar-tex, beastmanz, bikeridertim, Chuck in Indiana, David Abney, don, DWpistolpackin, ese927, EWK_Stuff, flaflash, Gmountain, grillzilla, hugelk, IHMSA80x80, jaggman, jenewman2, joseph, jpaul, JTecalo, Karl, littlejoe516, Mark, Maxwell 'Arlen' Silver, MrT182, ParaNormal, Pinetor, pops2, RS, Scott Rosenberger, shotgunboss, SIGWolf, snake-eye, stovepipe, tom, wdelack, willy, wpevey

Range Officers: brucertx, Dave_Ks, SHOOTIST357, Supermagfan, Tigger, zoommb

Dan’s Club: Blacktop, brucertx, Dave_Ks, Eric, ese927, freerider04, jaggman, lonwolf93, Ole Dog, ParaNormal, photohause, rebore41, SCORPIO, SHOOTIST357, Supermagfan, terry mc, willy, zoommb

Administrators: Jody, Steve CT

Moderators: lbruce, Charger Fan, rwsem
